Strands, cords and wire rope made of special-strength wire, designed primarily for use in aircraft industry and military applications. Due to its value, however, it is used widely for commercial applications as well. Aircraft Cable is specified by the number of strands in the rope, times the number of wires in each strand. (7 X 19 means that the rope has seven (7) strands x (19) wires in each strand) .
Specifications
* Federal Specification: RR-W-410D WIRE ROPE AND STRAND
* Military Specificatiuon:
MIL-DTL-83420
WIRE ROPE, FLEXIBLE, FOR AIRCRAFT
CONTROL
Type I -Non-Jacketed wire
rope
Type II -Jacketed wire rope
Composition A -Carbon steel, zinc, or tin
over zinc coated
Composition B -Corrosion
resistant steel
Black air craft
cable
Const. |
Structure |
Dia |
Min. B/S |
W'T/1000FT |
Packing Length |
7x7 |
 |
1/16" |
480 LBS |
7.50 LBS |
250FT 500FT 1,000FT 5,000FT |
7x19 |
| 3/32" |
1,000 LBS |
17.50 LBS |
|
1/8" |
2,000 LBS |
29.00 LBS |
|||
3/16" |
4,200 LBS |
65.00 LBS |
|||
1/4" |
7,000 LBS |
110.00 LBS |
|||
5/16" |
9,800 LBS |
173.00 LBS |
Galvanized aircraft
cable
Const. |
Structure |
Dia |
Tolerance (Dia) |
Min. B/S |
W'T/1000FT |
Application |
Packing |
7x7
|
|
3/64" |
0.008" |
270 LBS |
4.20 LBS |
* Dry(Commercial grade) * Good balance of Strength and Flexibility in Dia. less than 1/8". * Commonly used in Agriculture industry. | 250FT 500FT 1,000FT 5,000FT
|
1/16" |
0.010" | 480 LBS |
7.50 LBS |
||||
3/32" |
0.012" |
920 LBS |
16.00 LBS |
||||
1/8" |
0.014" |
1,700 LBS |
28.50 LBS |
||||
5/32" |
0.016" |
2,600 LBS |
43.00 LBS |
||||
3/16" |
0.018" |
3,700 LBS |
62.00 LBS |
||||
7/32" |
0.018" |
4,800 LBS |
86.00 LBS |
||||
1/4" |
0.018" |
6,100 LBS |
106.00 LBS |
||||
5/16" |
0.022" |
9,200 LBS |
167.00 LBS |
||||
3/8" |
0.026" |
13,300 LBS |
236.00 LBS |
||||
7x19
|
| 3/32" |
0.012" |
1,000 LBS |
17.50 LBS |
* Ideal for applications that involve a rope being cycled back and forth over pulleys and sheaves. * Lubricated * Commonly used in erosion control, irrigation and agriculture industry |
|
1/8" |
0.014" |
2,000 LBS |
29.00 LBS |
||||
5/32" |
0.016" |
2,800 LBS |
45.00 LBS |
||||
3/16" |
0.018" |
4,200 LBS |
65.00 LBS |
||||
7/32" |
0.018" |
5,600 LBS |
86.00 LBS |
||||
1/4" |
0.018" |
7,000 LBS |
110.00 LBS |
||||
9/32" |
0.020" |
8,000 LBS |
139.00 LBS |
||||
5/16" |
0.022" |
9,800 LBS |
173.00 LBS |
||||
3/8" |
0.026" |
14,400 LBS |
243.00 LBS |
* Other structures and diameters are also available.
Nylon coated GAC
Const. |
Structure |
Dia |
Min. B/S |
W'T/1000FT |
Color |
Packing Length |
7x19
|
| 1/8"-3/16" |
2,000 LBS |
39.00 LBS |
Clear Black |
250FT 500FT 1,000FT 5,000FT |
3/16"-1/4" |
4,200 LBS |
78.00 LBS |
||||
1/4"-5/16" |
7,000 LBS |
125.00 LBS |
||||
5/16"-3/8" |
9,800 LBS |
196.00 LBS |
||||
3/8"-7/16" |
14,000 LBS |
272.00 LBS |
Const. |
Structure |
Dia |
Tolerance | Min. B/S |
W'T/1000FT |
Packing | Application |
7x7
|
| 1/16" |
0.010" | 480 LBS |
7.50 LBS |
250FT 500FT 1,000FT 5,000FT
|
Commonly used in boat dock applications |
3/32" |
0.012" |
920 LBS |
16.00 LBS |
||||
1/8" |
0.014" |
1,700 LBS |
28.50 LBS |
||||
5/32" |
0.016" |
2,400 LBS |
43.00 LBS |
||||
3/16" |
0.018" |
3,700 LBS |
62.00 LBS |
||||
7x19
|
| 1/16" |
0.010" | 500 LBS |
7.50 LBS |
||
3/32" |
0.012" |
920 LBS |
17.00 LBS |
||||
1/8" |
0.014" |
1,760 LBS |
29.00 LBS |
||||
5/32" |
0.016" |
2,400 LBS |
45.00 LBS |
||||
3/16" |
0.018" |
3,700 LBS |
65.00 LBS |
||||
7/32" |
0.018" |
5,000 LBS |
86.00 LBS |
||||
1/4" |
0.018" |
6,400 LBS |
110.00 LBS |
||||
5/16" |
0.022" |
9,000 LBS |
173.00 LBS |
||||
3/8" |
0.026" |
12,000 LBS |
243.00 LBS |
* 7X19 construction is
both more flexible and more fatigue resistant than 7X7
construction.
SUS316 Stainless steel
aircraft
cable
Const. |
Structure |
Dia |
Tolerance (Dia) |
Min. B/S |
W'T/1000FT |
Packing Length |
Application |
7x19
|
| 1/8" |
0.014" |
1,670 LBS |
29.00 LBS |
250FT 500FT 1,000FT 5,000FT |
Ideal for salt water and marine applications |
3/16" |
0.018" |
3,565 LBS |
65.00 LBS |
||||
1/4" |
0.018" |
5,875 LBS |
110.00 LBS |
||||
5/16" |
0.022" |
8,825 LBS |
173.00 LBS |
||||
3/8" |
0.026" |
11,760 LBS |
243.00 LBS |
Const. |
Structure |
Diameter |
Min. B/S |
W'T/1000FT |
Color |
Packing Length |
|
Inner Cable |
Outer Cover |
||||||
7x7
|
| 3/64" |
1/16" |
270 LBS |
5.00 LBS |
Clear White Black Red Yellow Green Blue |
250FT 500FT 1,000FT 5,000FT
|
3/64" |
5/64" | 270 LBS |
6.00 LBS |
||||
1/16" |
3/32" |
480 LBS |
9.70 LBS |
||||
1/16" |
1/8" |
480 LBS |
12.90 LBS |
||||
3/32" |
1/8" |
920 LBS |
19.10 LBS |
||||
3/32" |
5/32" |
920 LBS |
23.20 LBS |
||||
3/32" |
3/16" |
920 LBS |
25.80 LBS |
||||
1/8" |
5/32" |
1.700 LBS | 32.60 LBS |
||||
1/8" |
3/16" |
1,700 LBS |
37.50 LBS |
||||
3/16" |
1/4" |
3,700 LBS |
74.60 LBS |
||||
3/16" |
5/16" |
3,700 LBS |
90.80 LBS |
||||
7x19
|
| 3/32" |
1/8" |
1,000 LBS |
20.60 LBS | ||
3/32" |
5/32" |
1,000 LBS |
24.60 LBS |
||||
1/8" |
5/32" |
2,000 LBS |
33.10 LBS |
||||
1/8" |
3/16" |
2,000 LBS |
38.00 LBS |
||||
5/32" |
7/32" |
2,800 LBS |
55.80 LBS |
||||
5/32" |
9/32" |
2,800 LBS |
70.10 LBS |
||||
3/16" |
1/4" |
4,200 LBS |
77.50 LBS |
||||
3/16" |
5/16" |
4,200 LBS |
93.80 LBS |
||||
1/4" |
5/16" |
7,000 LBS |
126.00 LBS |
||||
1/4" |
3/8" |
7,000 LBS |
146.00 LBS |
||||
5/16" |
3/8" |
9,800 LBS |
193.00 LBS |
||||
5/16" |
7/16" |
9,800 LBS |
216.00 LBS |
||||
3/8" |
7/16" |
14,400 LBS |
266.30 LBS |
||||
3/8" |
1/2" |
14,400 LBS |
293.30 LBS |
||||
Const. |
Structure |
Dia |
Min. B/S |
W'T/1000FT |
Color |
Packing Length |
7x19
|
| 1/8"-3/16" |
1,760 LBS |
36.20 LBS |
Clear White
|
250FT 500FT 1,000FT 5,000FT |
3/16"-1/4" |
3,700 LBS |
77.50 LBS |
||||
1/4"-5/16" |
6,400 LBS |
123.00 LBS |
Aircraft cable(Aircraft wire rope)
